RISEN RM300/580

Applied for mixing the cement  mortar or other similar materials suitable for being mixed slowly.

Mixing tank capacity: 300L

Agitator tank capacity: 580L

Mixing speed: 50r/min

Description:

RISEN RM300/580 is a double-layer mortar mixer. The upper layer is a mixing tank and the lower layer is an agitator tank. It is a good partner of the mortar pump.

Application:

Mixing the cement mortar (cement, sand and water) or the similar slurry suitable for being mixed slowly.

Features:

● Compact structure, mixing tank designed to be the upper of the agitator tank, be convenient for discharging;

● Rubber seal for the discharging outlet;

● High productivity, agitator tank’s capacity is about twice than the mixing tank’s;

Technical Data

Mixing tank capacity:

300 L

Agitator tank capacity:

580 L

Mixing speed:

50 r/min

Agitating speed:

33 r/min

Mixing Unit:

4 kW

Agitating Unit:

1.5 kW

Chassis:

kickstand

Dimensions:

1585×995×1500 mm

Weight:

400 kg

Advantage

● Tank body manufactured by the thicker plate for more reliable work and longer use life;

● Special welding handling;

● IP55 100% new electrical motor;

● Electrical control box manufactured by thicker plate and standard Schneider electrical elements;

● Painted after sandblasting for a pretty appearance.
