You are here : HOME> PRODUCTS >GROUT MIXER & MORTAR MIXER > RISEN RM250/700

Products List

RISEN RM250/700

High work efficiency grout mixer for cement slurry or other similar materials suitable for being mixed quickly. Mixing tank and agitator tank can be apart to be two separate units when transportation.

Mixing tank capacity: 250L

Agitator tank capacity: 700L

Mixing Speed: 1,400 r/min

Description:

RISEN RM250/700 is a high work efficiency grout mixer for compounding the cement and water. It consists of two separate tanks---mixing tank and agitator tank, more convenient for transportation.

It often works together with RISEN RG90 or other RG series grout pump.

Application:

Mixing the cement (or similar material) and water under high efficiency

Features:

● High mixing efficiency, motor directly driving impeller to get the high-speed liquid flow, about 2~3minutes to complete a mixing;

● High reliability, vertical-mount motor, easy to seal, low failure rate and good seal;

● Adopt the ordinary rubber pipe as consumable part for control valve, easy to get it on construction site;

Technical Data

Mixing tank capacity

250 L

Agitator tank capacity

700 L

Mixing speed

1400 r/min

Agitating speed

33 r/min

Mixing Unit

5.5 kW

Agitating Unit

1.5 kW

Chassis

kickstand

Overall Size of Mixing Tank

1190×750×1220 mm

Overall Size of AgitatingTank

1550x940x1832 mm

Weight

560 kg

Advantage

● Tank body manufactured by the thicker plate for more reliable work and longer use life;

● The whole stamping structure for the tank bottom;

● Special weld handling;

● IP55 100% new electrical motor;

● Electrical control box manufactured by thicker plate and standard Schneider electrical elements;

● Special-design seal structure for the pump;

● Painted after sandblasting for a pretty appearance.
